Heating and cooling equipment comes with manuals to keep users informed of their operation, maintenance, and other needs. Whenever you purchase a new Rheem heating or cooling system, be sure to store the manuals for future reference.

If you’ve lost your Rheem HVAC equipment manuals, HVAC.com is here to help! Download PDF copies of the manuals you need for quick access.

  • PDF Manual Technicial Manual SVC810 Second GenerationPV, X and DV, RTG2-42, RTG53, RTG66 and RTG74.pdf. User-manual-Tankless Hot Water Heater Rtg-74pvp-2 7.4 Gpm Manual. Nov 16, 2014 Rheem Tankless Hot Water Heater Rtg-74pvp-2 7.4 Gpm.
  • 21.47, ARI 340-370 and other Rheem-required reliability tests. Rheem adheres to stringent IS0 9002 quality procedures, and each unit bears the U.L. And ARI certification labels located on the unit nameplate ( ). Contractors can rest assured that when a Rheem package unit arrives at the job, it is ready to go with a factory charge and quality.

And Installation Instructions. E) Repairs, attempts to repair or modifications to the water heater by a person other than Rheem Service or a Rheem Accredited Service Agent / Centre. F) Faulty plumbing or faulty gas or power supply. G) Failure to maintain the water heater in accordance with the Owner's Guide and Installation Instructions.

Below, find the selection of Rheem HVAC equipment manuals we have available.

Rheem Gas Furnaces

Rheem gas furnaces offer reliable, efficient temperature control when outdoor conditions are chilly. The following Rheem gas furnace manuals are available for download.

Rheem Gas Furnace Customer Brochures:

RHEEMRGTM Consumer Manual
RHEEMRGTK Consumer Manual
RHEEMRGRM Consumer Manual
RHEEMRGRL Consumer Manual
RHEEMRGRK Consumer Manual
RHEEMRGPT Consumer Manual
RHEEMRGPS Consumer Manual
RHEEMRGPQ Consumer Manual
RHEEMRGPN Consumer Manual
RHEEMRGPE Consumer Manual
RHEEMRGLT Consumer Manual
RHEEMRGLS Consumer Manual
RHEEMRGLQ Consumer Manual
RHEEMRGLN Consumer Manual
RHEEMRGLE Consumer Manual
RHEEMRGJF Consumer Manual
RHEEMRGGE Consumer Manual
RHEEMRGFG Consumer Manual
RHEEMR96V Consumer Manual
RHEEMR96P Consumer Manual
RHEEMR95T Consumer Manual
RHEEMR95P Consumer Manual
RHEEMR92P Consumer Manual

Rheem Gas Furnace Owner’s Manuals:

RHEEMRGTM Owner Manual
RHEEMRGTK Owner Manual
RHEEMRGRM Owner Manual
RHEEMRGRL Owner Manual
RHEEMRGRK Owner Manual
RHEEMRGPT Owner Manual
RHEEMRGPS Owner Manual
RHEEMRGPQ Owner Manual
RHEEMRGPN Owner Manual
RHEEMRGPE Owner Manual
RHEEMRGLT Owner Manual
RHEEMRGLS Owner Manual
RHEEMRGLQ Owner Manual
RHEEMRGLN Owner Manual
RHEEMRGLE Owner Manual
RHEEMRGJF Owner Manual
RHEEMRGGE Owner Manual
RHEEMRGFG Owner Manual
RHEEM R96P Owner Manual
RHEEM R95T Owner Manual
RHEEM R95P Owner Manual
RHEEM R92P Owner Manual

Rheem Gas Furnace Specification Manuals:

RHEEMR96V Specification Manual
RHEEMR96P Specification Manual
RHEEMR95T Specification Manual
RHEEMR95P Specification Manual
RHEEMR92P Specification Manual

Installation

Rheem Gas Furnace Installation Manuals:

RHEEM Furnace Installation Manual – RGRM
RHEEM Furnace Installation Manual – RGPT
RHEEM Furnace Installation Manual – RGPS
RHEEM Furnace Installation Manual – RGPN
RHEEM Furnace Installation Manual – RGPE
RHEEM Furnace Installation Manual – RGLT
RHEEM Furnace Installation Manual – RGLS
RHEEM Furnace Installation Manual – RGLQ
RHEEM Furnace Installation Manual – RGLN
RHEEM Furnace Installation Manual – RGLE
RHEEM Furnace Installation Manual – RGFG
RHEEM Furnace Installation Manual – R96V
RHEEM Furnace Installation Manual – R96P
RHEEM Furnace Installation Manual – R95T
RHEEM Furnace Installation Manual – R95P
RHEEM Furnace Installation Manual – R92P

Rheem Oil Furnaces

Rheem oil furnaces deliver comfortable, even heat throughout living areas to create ideal indoor environments. The following Rheem oil furnace manuals are available for download.

Rheem Oil Furnace Customer Brochures:

RHEEM ROLA-P Consumer Manual
RHEEM ROCB-P Consumer Manual
RHEEM ROCB-E Consumer Manual
RHEEM ROCA-E Consumer Manual

Rheem Heat Pumps

Rheem heat pumps offer energy efficient heating and cooling, keeping your home or business comfortable no matter the season. The following Rheem heat pump manuals are available for download.

Rheem Heat Pump Customer Brochures:

RHEEM RPRL-JEC Consumer Manual
RHEEM RPQL-JEZ Consumer Manual
RHEEM RPQL-JAZ Consumer Manual
RHEEM RPNL-JAZ Consumer Manual
RHEEM 15PJL Consumer Manual
RHEEM 14PJM Consumer Manual
RHEEM 13PJL Consumer Manual

Rheem Heat Pump Installation Manuals:

RHEEM Heat Pump RPRL-JEC Installation Manual
RHEEM Heat Pump RPQL-JEZ Installation Manual
RHEEM Heat Pump RPQL-JAZ Installation Manual
RHEEM Heat Pump RPNL-JAZ Installation Manual
RHEEM Heat Pump 13PJL Installation Manual

Rheem Heat Pump Owner’s Manuals:

RHEEM RPRL-JEC Owner Manual
RHEEM RPQL-JEZ Owner Manual
RHEEM RPQL-JAZ Owner Manual
RHEEM RPNL-JAZ Owner Manual

Rheem Heat Pump Specification Manuals:

RHEEM 15PJL Specification Manual
RHEEM 14PJM Specification Manual
RHEEM 13PJP Specification Manual
RHEEM 13PJL Specification Manual

Rheem Air Conditioners

Rheem air conditioners keep homes and businesses cool using innovative, energy efficient technology. The following Rheem air conditioner manuals are available for download.

Rheem Air Conditioner Customer Brochures:

RHEEM RSPM Consumer Manual
RHEEM RASL-JEZ Consumer Manual
RHEEM RASL-JEC Consumer Manual
RHEEM RARL-JEZ Consumer Manual
RHEEM RARL-JEC Consumer Manual
RHEEM RAPM-JEZ Consumer Manual
RHEEM RAPM-JAZ Consumer Manual
RHEEM RANL-JAZ Consumer Manual
RHEEM 16AJL Consumer Manual
RHEEM 14AJM Consumer Manual
RHEEM 13AJN Consumer Manual

Rheem Air Conditioner Owner’s Manuals:

RHEEM RASL-JEZ Owner Manual
RHEEM RASL-JEC Owner Manual
RHEEM RARL-JEZ Owner Manual
RHEEM RARL-JEC Owner Manual
RHEEM RAPM-JEZ Owner Manual
RHEEM RAPM-JAZ Owner Manual
RHEEM RANL-JAZ Owner Manual
RHEEM 14AJM Owner Manual

Rheem Air Conditioner Specification Manuals:

RHEEM 16AJL Specification Manual
RHEEM 14AJM Specification Manual
RHEEM 13AJN Specification Manual

Rheem Air Handlers

Rheem air handlers work with forced air heating and cooling equipment to circulate conditioned air throughout the home or office. The following Rheem air handler manuals are available for download.

Rheem Air Handler Customer Brochures:

RHEEM RHWB Consumer Manual
RHEEM RHSL Consumer Manual
RHEEM RHPN Consumer Manual
RHEEM RHPL Consumer Manual
RHEEM RHML Consumer Manual
RHEEM RHLL Consumer Manual
RHEEM RHKL Consumer Manual
RHEEM RHBL Consumer Manual
RHEEM RHAL Consumer Manual
RHEEM RBHP Consumer Manual

Rheem Air Handler Owner’s Manuals:

Rheem Air Handler Installation Manuals:

RHEEM Air Handler RHWB Installation Manual
RHEEM Air Handler RHSL Installation Manual
RHEEM Air Handler RHPN Installation Manual
RHEEM Air Handler RHPL Installation Manual
RHEEM Air Handler RHML Installation Manual
RHEEM Air Handler RHLL Installation Manual
RHEEM Air Handler RHKL Installation Manual
RHEEM Air Handler RHBL Installation Manual

Rheem Evaporator Coils

Rheem evaporator coils absorb heat to improve the efficiency of the cooling process. The following Rheem evaporator coil manuals are available for download

Rheem Evaporator Coil Installation Manuals:

Rheem Packaged Air Conditioners

Rheem packaged air conditioners combine reliable heating and cooling equipment into one convenient to install, easy to access cabinet. The following Rheem packaged air conditioner manuals are available for download.

Rheem Packaged Air Conditioner Customer Brochures:

RHEEM RSNM Consumer Manual
RHEEM RSPL Consumer Manual
RHEEM RSNL Consumer Manual

Rheem Packaged Gas/Electric Units

Rheem rkmb installation manual transfer switch

Rheem packaged gas/electric units combine gas and electric heating system in one convenient cabinet to fulfill the heating needs of your home or business. The following Rheem packaged gas/electric unit manuals are available for download.

Rheem Packaged Gas/Electric Unit Customer Brochures:

RHEEM RRRL Consumer Manual
RHEEM RRPL Consumer Manual
RHEEM RRNL Consumer Manual

Rheem Rkmb Installation Manual Troubleshooting

Rheem Packaged Heat Pumps

Rheem packaged heat pumps combine efficient heat pump and air handling equipment in one convenient cabinet to deliver comfort throughout your home or workplace. The following Rheem packaged heat pump manuals are available for download.

Rheem Packaged Heat Pump Customer Brochures:

RHEEM RQRM Consumer Manual
RHEEM RQPM Consumer Manual
RHEEM RQPL Consumer Manual
RHEEM RQNM Consumer Manual
RHEEM RQNL Consumer Manual

Rheem Packaged Heat Pump Installation Manuals:

RHEEM RQRM Installation Manual
RHEEM RQPM Installation Manual
RHEEM RQNM Installation Manual

Find Rheem HVAC Technicians on HVAC.com

Use HVAC.com’s Contractor Directory is a resource for homeowners, connecting you to skilled, local heating and cooling professionals who perform installation, repair service, and maintenance for Rheem heating and cooling equipment. Input your ZIP code to find contact details and services provided by each company so you can make the best decision when selecting an HVAC pro to work with.

Related Posts

December 20, 2019

Rheem Rkmb Installation Manual

How to Find the Best Mini Window Air Conditioner

December 20, 2019

Software Installation Manual

Air Conditioner Troubleshooting Guide

Rheem water heater troubleshooting allows you to find pressure relief valve to some common issues or indicates professional repair or replacement is needed. This guide to common water heater problems covers gas and electric models from Rheem, Ruud, and other brands.

Before taking the Rheem water heater pressure relief valve below, it’s worth remembering the potential dangers – burns from hot water or the tank, shock from electrical connections and the risk of a gas leak or carbon monoxide leak from gas models. Only take Rheem water heater troubleshooting steps you’re knowledgeable about and comfortable with. Calling a Rheem water repair technician is an affordable way to avoid serious injury.

Our Favorite Rheem Water Heaters

No products found.

Rheem Water Heaters – Common Issues

Here’s a list of the most common Rheem water heater problems to look for. Solutions requiring multiple steps are found below.

No Hot Water

A tripped circuit breaker will shut down an electric heater and gas models that use electricity.

  • Gas: Check if the gas valve has been turned off. If you use propane, your tank might be empty. If the unit has a pilot light (see your manual), check to see if it is lit.
  • Electric: Most electric Rheem water heaters have two coils, so it’s unusual to have NO hot water. Check the circuit in the electrical box to make sure it hasn’t been tripped. If it is on, it’s possible the circuit breaker in the box has failed.

Not Enough Hot Water

If the water heater is new, or if you’ve just moved into a new home and aren’t familiar with the water heater’s capability, it’s likely that the unit is undersized. You’re using hot water faster than it can make it. This problem is more common with electric models since they don’t heat water as quickly as gas models.

  • Gas: If the burner is firing, but you’re not getting enough hot water, the unit is too small, the gas valve is plugged with debris from age or the temperature is set too low.
  • Electric: If this is a new problem, then one of the two heating elements or thermostats is probably bad.
  • Mineral deposits: There’s another reason for this issue, and it applies where very hard water is being used. Mineral deposits build up in a tank, so that within three to five years, especially if the tank isn’t periodically drained, mineral buildup can reduce capacity by up to 15 gallons.

There’s Water on the Floor

The water could be coming from a leaking tank, more common in old water heaters, a loose fitting or normal discharge from the temperature pressure T&P relief valve.

No products found.

Tools You’ll Need for the Job

This small collection of items will assist you in Rheem water heater troubleshooting and possibly making a repair.

  • Your owner’s manual: There’s likely a section in the manual on Rheem water heater troubleshooting that will address the issue you’re having. If you don’t have the manual, you can probably find it online by searching the model name or number.
  • Flathead and Philips screwdrivers
  • Electrical tester
  • Pipe tape: Make sure it is for water and not gas.
  • Small plumber’s wrench
  • Bucket and towels
  • BBQ-style lighter
  • Heating element wrench (electric models only): An element wrench like this one can be purchased for $9-$15 at home improvement stores and online sellers.

Rheem Water Heater Troubleshooting

Here are tips for solving your Rheem water heater problem or deciding to call a Rheem service company to handle the repair.

No Hot Water

All electric water heaters and gas heaters that use electricity: The first issue to troubleshoot is a lack of power to the unit.

  • If the water from the hot tap goes cold, give a gas unit 15 minutes and an pressure relief valve 30 minutes to start making enough hot water for you to notice at the tap. However, if the water remains cold, it’s safe to say the unit isn’t heating water.
  • If the circuit breaker in your electrical panel is in the “Off” position, turn it to the “On” position. If it is midway between the two, it has been tripped. Turn it all the way to “Off”, and then turn it to the “On” position. If the circuit continues to trip, there’s an electrical issue that needs to be diagnosed and repaired by a qualified service technician.

Gas water heater: If your unit has a pilot light and it isn’t lit, follow the instructions in your user’s manual to relight the pilot using the BBQ lighter. If the unit has an electronic ignition and it won’t fire, the ignition might require replacing. Since replacing it involves the potential for a gas leak if not handled properly, consider calling a repair technician for the work.

No products found.

Not Enough Hot Water

Gas water heater

If your gas water heater isn’t making enough hot water, try adjusting the thermostat to a higher setting. This might require a flat screwdriver placed in the slot on the adjuster. The manual has detailed instructions.

Caution: It’s recommended that you set the thermostat no higher than 120 degrees Fahrenheit to reduce the risk of severe burns from scalding. If the unit still doesn’t make enough hot water, it is either undersized for your needs, partially filled with mineral sediment or has a plugged gas valve. A Rheem technician can check the gas valve and clean or replace it.

Electric water heater

If you’re getting some hot water, and you can hear the unit heating, check the thermostat set point. Adjust it to a higher temperature, but no higher than 120F. If the water continues to be warm but not hot or heats very slowly, then one of the heating elements or thermostats is bad.

  • Use the electrical tester to test the heating elements and thermostats. Electrical current won’t pass through a bad part. Parts like this Rheem element and this Rheem thermostat are available online and at home improvement stores for less than $15. Titanium elements are available for about $50 if you want to reduce the chance of having to replace it again.

Replacing an Element/Thermostat

To replace an element or thermostat:

  • Turn off the double 240V circuit in the electrical panel for the water heater.
  • When replacing a heating element, shut off water leading to the water heater. Turn off the pump’s circuit, if you have a well and pump. Open a hot water faucet in a tub until the water stops flowing. This takes pressure off the water tank.
  • Remove the part from its packaging. Do the same with the wrench when replacing a heating element.
  • Use a screwdriver to disconnect the wires to the bad element or thermostat.
  • Place a couple towels on the floor if replacing an element. Quickly loosen the element with the wrench first and then with your hand. Pull it out quickly, insert the new element, and hand-tighten it. Then, use the wrench to tighten it until there are no leaks. Be careful not to overtighten it.
  • If replacing the thermostat, take a digital picture of the thermostat’s wiring before removing the wiring and the bad part. Install the new thermostat. Check the picture to ensure proper wiring.

Note: If you’d prefer not to have a small amount of water leak from the tank while replacing the element, drain the tank first by attaching a garden hose to the threaded spigot near the bottom of the tank, running the hose to a floor drain or to the outside of your home and turning on the spigot.

There’s Water on the Floor

If this problem starts immediately after you install or repair a water heater, a fitting is probably loose. Turn off power to the unit, if applicable, and check all pipe connections for water. Gently tighten any wet connection. The connection should have pipe tape on it and be very snug, not overly tight. If you replaced an electric element, remove the cover to it, and check/tighten the element if necessary.

In Case Everything Is Set

Switch

If everything is tight, the next step is to determine if the relief valve releases water.

  • Place a bucket on the floor beneath the valve or hang a light bucket from it, and if there is only water in the bucket the next time it leaks, you’ve found the source.
  • If the thermostat is set above 120F, turn it down to that temperature or lower. Having the thermostat set too high will cause water expansion and force water out the valve.

If Water Is Still Dripping

If water continues to drip or flow from the temperature/pressure relief valve, you can replace it with the following steps:

  • Purchase the right valve for your model. Your manual should have a parts list in it, or you can find one online. Common Rheem T&P valves like this one cost less than $20.
  • Turn off power and water to the unit, and turn off the well pump, if applicable.
  • Either run hot water at a tap for a few minutes or through a hose attached to the drain near the bottom of the tank. This should lower the water level to below the valve location.
  • Flip open the relief valve to take any remaining pressure off the tank.
  • Using a wrench, loosen the old valve by turning left/counter-clockwise.
  • Wrap pipe tape clockwise around the new valve’s threads, and install it, tightening by hand until snug.
  • Use the wrench to continue tightening it one-quarter to one-half of a turn
  • Turn the power and water back on. Allow the water to heat up. If the valve leaks because it is too loose, tighten it another quarter to half a turn.

Rheem Install Manual

If water isn’t coming from a fitting or the T&P relief valve, the tank is leaking. It’s probably time for a new water heater.

No products found.

Caution Notes

We’ve included several safety steps in this Rheem water heater troubleshooting guide to prevent burn and shock. Here are additional warnings:

  • If you smell gas around a gas water heater, turn off the gas valve and don’t ignite anything. Evacuate your home, and call a repair technician or the gas company.
  • Since deadly carbon monoxide (CO) is a byproduct of the combustion of natural gas and propane, it is important to install a CO detector near a gas water heater. If the carbon monoxide detector goes off, evacuate the area. Call 911 or a service technician immediately.

Rheem Rkmb Installation Manual Transfer Switch

Rheem Water Heater Troubleshooting Summary

If you didn’t find the issue you’re having here or these steps don’t solve it, a service technician can help. They can evaluate whether you can repair or replace your water heater. Replacement makes sense if the unit is 7+ years old and the repair is a costly one. Finally, if you managed to solve your issue, sharing these Rheem water heater troubleshooting tips on social media might benefit others. They apply to any brand water heater.
